AC WORKS® [ASINL530P] 30-Amp 125-Volt L5-30P Power Input Inlet UL and C-UL Listed

This AC WORKS® brand inlet wiring device is a heavy-duty power input connection device.  It is used for an industrial and commercial grade flange inlet.  This inlet works with 10 AWG (American Wire Gauge) copper wire and is commonly used for boats, RVs and small trailers or cabins, residential, transfer switches, and generators.  Included in your purchase is a 1-year limited warranty.

This product requires mounting holes with a saw size between 2.10'' (53.34mm) to 2.3'' (58.42mm).

Note: 18 Gauge is for 10 Amp, 16 Gauge is for 13 Amp, 14 Gauge is for 16 Amp, 12 Gauge is for 20 Amp.

Features

• Residential, Generator, Transfer Switch, and Cabin Power Inlet
• 30 Amp, 125 Volt Inlet
• NEMA L5-30P Locking Power Inlet
• cULus E237606

• Includes Screws
• 1-year Limited Warranty

Common Uses

• Emergency Power
• Temporary Power
